Technical Specifications

SYSTEM

40,000 BTU main burner output

635 sq. in. / 4,100 sq. cm. total cooking space including porcelain coated warming rack

400 sq. in. / 2,600 sq. cm. primary cooking space

Heavy-duty cast iron cooking grids

Stainless steel Flav-R-Wave™ cooking system

Flav-R-Zone™ heat partitions

Three stainless steel Dual-Tube™ burners

Linear-Flow™ valves with 180° sensi-touch™ control

Sure-lite™ electronic dual-electrode ignition system

Deluxe Accu-Temp™ thermometer
DESIGN

Therma-cast™ aluminium cookbox with stainless steel wrap

Rigid steel cabinet with stainless steel doors

Rust proof resin base

Stainless steel drop-down side shelves

Large 7″ / 18 cm crack-proof wheels

Large 2.5″ / 6.4 cm locking casters

Rust resistant zinc coated steel components

Premium powder-coat black epoxy paint finish
FUEL TYPE

Propane (LP) – designed for use with 20lb tank – not included.

– or –

Natural Gas (NG) – 10ft natural gas hose included.
ASSEMBLED GRILL DIMENSIONS

48.4 in. Height 23.2 in. Width 56.5 in. Length
GRILL WEIGHT

134.0 lbs (LP Model) 134.0 lbs (NG Model)
COOKING SURFACE

15.12 in. Width, 25.56 in. Length
COVER

Broil King® Premium Grill Cover 67487 fits the Signet™ 320

Crafted from water resistant PVC with durable woven polyester lining. They feature mesh venting for enhanced air flow and moisture resistance as well as velcro closures for a superior fit. Blue accent stitching adds style to the extra reinforced seams. Molded rubber handles make the cover easy to remove.

WARRANTY

We reward quality. This Broil King® features a 2 Year Warranty.
